Steel Enclosed Trailers

---

Specs

• All Tube Perimeter Main Frame
• Tube Roof Bows
• Tube Walls
• 18" V-Nose on 5' & 6' Models
• 24" V-Nose on 7' & 7.5' Models
• 24" V-Nose on 8' Models
• Radial Tires on Silver Mod Steel Wheels
• 2 5/16" Coupler  *Tandem Axle Units
• 2" Coupler  *Single Axle Units
• Dexter Torsion Axles w/ Greaseable Hubs
• Electric Brakes on Tandem Axle Models
• ATP Fenders
• 2000# Top Wind A-Frame Jack
• 3/4" Engineered Wood Floor
• 3/8" Engineered Wood Walls
• Interior Dome Light
• 24" ATP Stone Guard
• Flo-Thru Vents

• Single Rear Door on 5' Wide Model *Ramp Optional
• Rear Ramp Door Standard on All Other Models *Double Doors Optional
• Seamless One Piece Aluminum Roof
• Corrosion Resistant Zinc Door Hardware
• LED Exterior Lights
• Side Door Not Available on 5' Wide Models
• 30" Side Door on 6', 7' & 7.5' Wide Models
• ​36" Side Door on 8.5' Wide Models
• Screwless Aluminum Exterior Skin
• 10 Year Axle & 2 Year Frame Warranty

Sizes-

• 5' Wide x 8'-10' Long
• 6' Wide x 10'- 14' Long
• 7' Wide x 12'-20' Long
• 7.5' Wide x 12'-20' Long
• 8.5' Wide x 16'- 28' Long


Axles-

*Single & Tandem Axle Options Available

• 3,500# Torsion Axles
• 5,200# Torsion Axles
• 6,000# Torsion Axles
• 7,000# Torsion Axles

​

Colors-

*No Additional Charge for Standard Colors

• Victory Red
• Black
• White
• Metallic Charcoal
• Pewter
• Silver

​*Other Colors Available for Additional Charge

Specs

• Steel Tube Frame
• Steel Formed Channel Crossmembers
• Steel Tube Wall Uprights
• Galvanized Steel Tube Row Bows
• Body Fully Undercoated
• Vapor Barrier
• Flat Roof with .024 Aluminum Sheeting (attached to each roof bow)
• 72" Interior Height
• 30" Wedge Front
• Steel Triple Tube Tongue
• ​2 5/16" Posi-Lock Coupler
• Dual Safety Chains & Hooks
• 2,000# Rated Coupler Mount Jack *10K Models
• 7000# Drop Leg Jack *14K Models
• .030 Aluminum Exterior Sheeting
• Dovetail

• 24" Aluminum Tread Plate Rock Guard
• Weather Coated Tongue & Rear Bulkhead
• 3/8" Engineered Wood Interior Walls
• Aluminum H-Channel Wall Transitions
• 3/4" Engineered Wood Flooring
• 36" Side Door w/ RV Latch
• ​4 D-Rings in Floor
• Aluminum Door Hold Back
• Spring Assist Rear Ramp Door
• Aluminum Teardrop Fenders
• Easy Lube Hubs
• ​Radial Tires on White Steel Wheels
• Wall Mounted 12V LED Dome Lights & Switch
• ​LED Lights

Sizes-​

• 8.5' Wide x 20'-28' Long


Axles-

• ​Tandem Axle
  • ​2- 5,200#
  • ​2- 7,000#


Colors-

• White
• Black
• Charcoal
• Silver


​ *Other Colors Available for Additional Charge
